SERIE P VALVOLA A SFERA
QUICK DISCONNECT COUPLINGS
| sizebase | ∅ dn | code | ∅ a * | b | c | d | l | ch1 | ch2 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | plug | socket | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | ||||||||
| 08 | 12 | 1/2" |
|
|
|
46 | 1.81 | 67 | 2,64 | 38 | 1.50 | 92 | 3.62 | 27 | 1.06 | 24 | 0.94 | ||||||
* Other threads available on request
MAIN DATA:
The P series push-pull couplings are interchangeable according to
ISO 7241-A and ISO 5675.
These couplings are normally adopted on agricultural implements and applications; the possible panel mounting allows to easily connect and disconnect plug and socket with one hand only.
P series couplings are available with both poppet valve and ball valve; the standard thread are BSP, NPTF and metric male 24° according to DIN 2353.
Main data:
- Poppet or ball valves
- Interchangeable ISO 7241-A and ISO 5675
- Material: steel
- Poppet valve in hardened steel
- Plug in hardened steel
- Working temperatures with standard seals -20 C° / +110 C°
- Standard seals in nitril rubber
- Back-up ring in teflon
Special features:
a special valve is available on request to allow the plug to be connected in presence of residual back pressure.
