SERIE HP
FLAT FACE COUPLINGS
| sizebase | ∅ dn | code | ∅ a * | b | c | d | l | ch1 | ch2 | |||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | plug | socket | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | ||||||||||||||||||||
| 04 | 5 |
|
|
|
48 | 1,89 | 58 | 2.28 | 29 | 1.14 | 95 | 3.74 | 22 | 0.87 | 22 | 0.87 | ||||||||||||||||||
| 06 | 8 |
|
|
|
61 | 2.40 | 70 | 2.76 | 34 | 1.34 | 114 | 4.49 | 27 | 1.06 | 30 | 1.18 | ||||||||||||||||||
* Other threads available on request
MAIN DATA:
Series HP include flat face couplings designed for the very high pressures typical of hydraulic tools and powerpacks (720 bar/10.000 psi).
- Perfect sealing of plug and socket both when coupled and uncoupled.
- Extremely low spillage during connection and disconnection.
- No inclusion of air or external media during connection and disconnection.
- The flat faces are easy to clean.
- Sleeve with a safety device preventing from accidental disconnection
- Standard seals in nitril rubber
- Antiextrusion ring in teflon
- Working temperature with standard seals: -20° C/ +110° C.
- Special seals on request.
